Introduction：

Items can be stored by using the biometric fingerprint recognition method for opening the box. The fingerprint storage cabinet has the characteristics of high security, convenient operation, and not requiring carrying a receipt with you. The user can record their fingerprints, and the access operation is simple. No consumables are needed during use.

 FEATURES：

一、 Characteristics and Advantages

1. Self-service fingerprint storage mode, temporarily input fingerprints, and the storage is valid for one time.
2. Large-area capacitive biometric fingerprint recognition module, fingerprint recognition response time is 0.3 seconds.
3. Compatible with fingerprints or ID/IC cards as the storage voucher, local administrators can emergency open the box.
4. Administrators use electronic keys (management IC card + password) to enter the management interface.
5. The records of storage and retrieval of each box, the operation records of administrators, and the full box clearance records can all be printed out.

二、standard configuration：

1. The fingerprint scanner completely solves the problem of low fingerprint recognition rate for imperfect fingers. It is made of high-quality stainless steel, with high recognition rate, fast and accurate. Even for fingers that have been soaked in water or are dirty (as long as the fingers are not damaged), it can still achieve 100% recognition rate.
2. Touch-type buttons, micro-motion buttons with backlight, have a lifespan of more than 100,000 times, are sensitive, thin and durable.
3. Administrators can instantly clear the contents of the locker or bind specific door(s).
4. It has infrared detection function for items (optional) and voice prompt function.
5. There is a backup power supply. When the power is off, it can be used normally for no less than 4 hours; after the power is cut off, the data will be automatically saved (optional).
6. Fingers can be bound to a specific locker door or a specific user. Only authorized users can use it.

三、operation procedure

Storage: Press the "Save" key on the keyboard, then press your fingerprint in the fingerprint collection window. The system will associate this fingerprint with a certain allocated box door, and the corresponding box door will automatically open.
Withdrawal: Press the "Retrieve" key on the keyboard, then press your fingerprint in the fingerprint collection window. The cabinet door corresponding to the box number will automatically open.

 Product specification：

Cabinet dimensions: Height 1800mm * Width 1600mm * Depth 450mm (customizable)
Single cabinet dimensions: Height 280mm * Width 304mm * Depth 450mm (customizable)
Product model: YTS-2409
Board thickness: 0.8mm - 1.0mm
Cabinet material: High-quality carbon steel
Surface treatment: High-temperature baking leveling and curing anti-static powder coating
Power supply: 220V
Authentication method: Fingerprint (customizable options include password, barcode, QR code, card swipe, face recognition)
Display screen: 128*64 dot matrix screen

store goods:

Backpack, clothes, wallet, jewelry, mobile phone

Usage scenarios:

Shopping malls, enterprises and institutions, public security and judicial units, military units, prisons, schools, museums, libraries, stations, airports, clubs, swimming pools

 color:

Personalized color schemes allow you to match custom colors that belong to you according to the usage environment.
